Locomotive Applied reactor

1. products are used in rail transportation such as high speed rail, subway, city rail and so on.
2. product design through low noise technology, strong overload capacity, high impedance short circuit capacity, high mechanical strength, high anti harmonic, high vibration resistance, large current impact resistance and thermal shock without cracking, free suspension structure etc..

咨询我们 0755-27139706

详细介绍

Locomotive Application reactor product description:

1. products are used in rail transportation such as high speed rail, subway, city rail and so on.

2. product design through low noise technology, strong overload capacity, high impedance short circuit capacity, high mechanical strength, high anti harmonic, high vibration resistance, large current impact resistance and thermal shock without cracking, free suspension structure etc..

Technical Parameters of DC Reactor for Rail Transit
	Item	Standard Value	Condition
1	Inductance value	0.1mH-100mH
2	Current range	＜2000A
3	Insulation resistance	＞100MΩ	DC1000V
4	Dielectric strength	＜20mA	AC5.5KV 60s
5	Noise	≤75dB	1m away from transformer
6	Temperature rise	≤125K	Full load, forced air cooling
7	Insulation class	Class H (180℃)
8	Ambient temperature	-40℃ - 50℃
9	Design standard	GBT10229

Application of locomotive reactor

Rail transit
